Offering an unprecedented combination of comfort, efficiency, and nimble handling, the Sirrus X excels on pavement, dirt, and any terrain in between. SMOOTH, COMFORTABLE, AND EFFICIENT: The patent pending Compliance Junction frame design of the Sirrus X provides the smoothest ride in its class. Engineered vertical compliance without sacrificing lateral rigidity translates to more comfort, control, and efficiency on all roads, paved or gravel. RIDER-FIRST ENGINEERED: Like all Specialized carbon bikes, the geometry of each frame is uniquely crafted. This means that for every frame, each tube size and carbon layup is specifically selected to achieve the optimal balance of rigidity, weight, and responsiveness to ensure that no matter what size you're riding, you're going to experience the world's best ride. NIMBLE: Class-leading light-weight, exceptional pedaling efficiency, and steering precision merge for confident, nearly telepathic handling characteristics. Specialized FACT 9r carbon frame features internal cable routing.Using our Rider-First Engineered philosophy, the geometry of each frame is uniquely crafted. Each tube size and carbon layup is specifically selected to achieve the optimal balance of rigidity, weight, and responsiveness no matter the frame size.The Compliance Junction provides just the right amount of flex and forgiveness across the carbon frame without sacrificing performance and efficiency.Future Shock 1.5, Specialized's unique suspension design, is placed inside the headtube to prevent harsh frequencies caused by bumps in the road from reaching the handlebars.Wide 38c Pathfinder tubeless-ready tires are ideal for mastering variable terrain, providing traction and comfort off the beaten path.The minimalist yet efficient SRAM NX Eagle 1x drivetrain with wide-range gearing ensures smooth and reliable shifting.Tektro hydraulic brakes with large 160mm rotors provide reliable stopping power on- and off-road.Sirrus X 5.0 is fender and rack compatible with top tube and fork mounts, and racks can be used with 51c DRYTECH fenders, making Sirrus easy to rack and roll.
| Crank Length | 165 | 165 | 170 | 170 | 170 | 170 | 175 | 175 | 175 | 175 | 175 | 175 |
|---|
| Handlebar Width | 680 | 680 | 680 | 680 | 680 | 680 | 680 | 680 | 680 | 680 | 680 | 680 |
|---|
| Stem Length | 60 | 60 | 70 | 70 | 80 | 80 | 90 | 90 | 100 | 100 | 110 | 110 |
|---|
| Saddle Width | 155 | 155 | 155 | 155 | 143 | 143 | 143 | 143 | 143 | 143 | 143 | 143 |
|---|
| Seatpost Length | 300 | 300 | 300 | 300 | 350 | 350 | 350 | 350 | 400 | 400 | 400 | 400 |
|---|
| Stack | 580 | 600 | 625 | 650 | 680 | 710 |
|---|
| Reach | 350 | 365 | 380 | 395 | 410 | 425 |
|---|
| Head-Tube Length | 107 | 128 | 151 | 176 | 208 | 237 |
|---|
| Head-Tube Angle | 69.5 | 69.5 | 70 | 70.5 | 70.5 | 71 |
|---|
| B-B Height | 268 | 268 | 268 | 268 | 268 | 268 |
|---|
| B-B Drop | 80 | 80 | 80 | 80 | 80 | 80 |
|---|
| Trail | 76 | 76 | 72 | 69 | 69 | 66 |
|---|
| Fork Length (full) | 395 | 395 | 395 | 395 | 395 | 395 |
|---|
| Fork Rake/Offset | 51 | 51 | 51 | 51 | 51 | 51 |
|---|
| Front-Center | 597 | 619 | 637 | 656 | 681 | 700 |
|---|
| Chain-Stay Length | 440 | 440 | 440 | 440 | 440 | 440 |
|---|
| Wheelbase | 1024 | 1047 | 1065 | 1084 | 1109 | 1128 |
|---|
| Top-Tube Length (horizontal) | 521 | 547 | 568 | 590 | 614 | 644 |
|---|
| Bike Stand-Over Height | 703.3 | 748.3 | 780.5 | 807.1 | 847.7 | 872.5 |
|---|
| Seat-Tube Length | 355 | 416 | 453 | 483 | 533 | 563 |
|---|
| Seat-Tube Angle | 74 | 73.5 | 73.5 | 73.5 | 73.5 | 73 |
|---|
Frameset- Frame: Specialized FACT 9r Carbon, Fitness Geometry, 1x Drivetrain, 12x142 thru-axle, internal cable routing, flat-mount disc, Plug + Play rack/fender mounts
- Seat Binder: Integrated w/ frame
Suspension- Fork: Specialized FACT 9r Carbon Monocoque, flat-mount disc, 12x100mm thru-axle, low rider mounts, Plug + Play fender mounts, Future Shock 1.5
Brakes- Front Brake: Tektro HD-R510, hydraulic disc, 160mm
- Rear Brake: Tektro HD-R510, hydraulic disc, 160mm
Drivetrain- Chain: SRAM NX Eagle, 12-speed
- Rear Derailleur: SRAM NX Eagle, 12-speed
- Cassette: SRAM PG-1210 Eagle, 11-50t
- Bottom Bracket: SRAM Powerspline
- Crankset: SRAM S650, 3-piece, Powerspline
- Shift Levers: SRAM SL NX Eagle Trigger
- Chainrings: 38T
Wheels & Tires- Rims: 700C disc, double-wall alloy, 30mm depth, 21mm internal width
- Front Hub: Alloy, sealed cartridge bearings, Center Lock, 12x100mm thru-axle, 24h
- Rear Hub: Alloy, sealed cartridge bearings, Center Lock, 12x142mm thru-axle, 28h
- Front Tire: Pathfinder Pro, 2Bliss Ready, 700x38mm
- Rear Tire: Pathfinder Pro, 2Bliss Ready, 700x38mm
- Inner Tubes: 700x28/38mm, 48mm Presta valve
- Spokes: Stainless, 14g
Cockpit- Handlebars: Double-butted alloy, 9-degree backsweep, 15mm rise, 31.8mm
- SeatPost: Alloy, 2-bolt, 14mm offset, 27.2mm
- Saddle: Body Geometry Power Sport, steel rails
- Stem: Future Stem, Comp
- Grips: Specialized Neutralizer, Body Geometry, locking grip
Accessories- Pedals: VP Platform, Alloy Body
Weight- Weight Size: LG
- Weight: 10.6kg (23 lb, 5.9 oz)
|
